Wilo Stratos MAXO 25/0,5-4 PN 10 – Artikelnummer 2164567
Die Wilo Stratos MAXO 25/0,5-4 ist eine moderne, elektronisch geregelte Smart-Hocheffizienzpumpe für Heizungsanlagen, Kühl-/Klimasysteme und gewerbliche Anwendungen. Mit EC-Motor-Technologie, Dynamic Adapt plus und umfangreichen Regelungsarten bietet sie höchste Energieeffizienz und Betriebssicherheit – ideal für anspruchsvolle Anlagen.
- Premium Nassläuferpumpe mit EC-Motor
- Sehr effizient – Energieeffizienzindex (EEI) ≤ 0,18
- Integrierte elektronische Leistungs- und Differenzdruckregelung
- Großes 4,3" Farb-Display für Förderhöhe, Volumenstrom & Verbrauch
- Dynamic Adapt plus – automatische Leistungsanpassung
- Wärme- und Kältemengenerfassung integriert
- Automatische Nachtabsenkung, No-Flow Stop & Trockenlauferkennung
- Bluetooth-Schnittstelle für Wilo Assistant App
- Einfacher Elektroanschluss durch Wilo-Connector
- Artikelnummer: 2164567
- Spannung: 1~ 230 V, 50/60 Hz
- Leistungsaufnahme: 7–80 W
- Stromaufnahme: 0,11–0,58 A
- Förderhöhe: bis zu 4,2 m
- Volumenstrom: bis zu 8,1 m³/h
- Baulänge: 180 mm
- Rohranschlüsse: G 1½
- Medientemperatur: -10 °C bis +110 °C
- Max. Betriebsdruck: 10 bar (PN 10)
- Schutzart: IPX4D
- Isolationsklasse: F
- Umgebungstemperatur: max. 40 °C
- Gewicht: ca. 7,2 kg
- Gehäuse: Grauguss
- Laufrad: PPS-GF40
- Welle: Edelstahl
- Lager: Kohlegraphit
- Δp-v – variabler Differenzdruck
- Δp-c – konstanter Differenzdruck
- Q-Limit – Begrenzung des Volumenstroms
- Dynamic Adapt plus – automatische Anpassung ohne Sollwert
- T-const. – konstante Temperatur
- ΔT-const. – konstante Differenztemperatur
- Konstant Q – konstanter Volumenstrom
- PID-Regelung – benutzerdefiniert
- Drehzahlkonstant (n-const.)
- Multi-Flow Adaptation – optimierter Pumpenverbund
Ideal für moderne Heizsysteme, Kühlkreisläufe, Fußbodenheizungen und gewerbliche Anlagen, die höchste Effizienz, geringe Betriebskosten und smarte Steuerungsmöglichkeiten benötigen.
- Bluetooth zur Nutzung der Wilo Assistant App
- Analogeingänge: 0–10 V, 2–10 V, 0–20 mA, 4–20 mA, Pt1000
- Digitale Eingänge: Ext. AUS, Ext. MIN, Ext. MAX, Heizen/Kühlen, Tastensperre
- Digitale Ausgänge: SSM, SBM
- Kompatibel mit Wilo-Smart Cloud (mit Smart Gateway)
- Optional: BACnet, LON, Modbus, CANopen, PLR
