A++ Woody water-bearing pellet stove 24 kW with white ceramic cladding

A mix of elegance and efficiency.

The water-fired pellet stove from Robin Wood is a true masterpiece. With an efficiency of more than 94% and an energy efficiency class of A++, it ensures environmentally friendly and clean combustion of wood pellets.
Equipped with automatic burner cleaning, it offers you a high level of user-friendliness and comfort.

Thanks to its balanced heat distribution (3.1 kW heat output in the installation room and 21.1 kW to the buffer tank), it provides your living space with plenty of heat without overheating the rooms.
The large ash box ensures long intervals between cleaning.

Equipped with all technical components (Wilo high-efficiency pump, safety temperature limiter, expansion vessel, safety valve, system pressure sensor, etc.), it enables you to quickly install it in your heating system.


The handmade Italian ceramics and the double glass door give your home a cozy atmosphere and an elegant touch. When the stove is not on, the view of the combustion chamber is obscured, the combustion chamber only becomes visible through the flame.

The ceramic cladding can be changed at any time regardless of the color ordered, choose between:
• Ceramic white with black accents
• Ceramic Black Complete
• Bordeaux ceramic with black accents

✓ BAFA eligible in Germany

• see bafa.de
• We will be happy to help you fill out the BAFA application

✓ Technical data Robin Wood Woody 24 kW:

▸ Heat output when installed in room: 3 kW
▸ Height H: 1051mm
▸ Width B: 626mm
▸ Depth T: 620mm
▸ Pellet tank capacity: 30 kg
▸ Fresh air connection: Ø 48mm
▸ Smoke pipe: Ø 80mm
▸ Weight: 192 kg
▸ Fuel type: Pellets Ø6 - Ø 8mm
▸ Chimney draft: 12 Pa
▸ Power consumption: 60/310W
▸ Power connection: 230/50 V/Hz
▸ Water jacket capacity: 41 liters
▸ Operating pressure: 0.5 - 0.2 bar
▸ Possible ambient temperature during operation: 5-40°C
▸ Humidity at 30°C ambient temperature: 85%
▸ Efficiency: >94%
▸ CO emissions: >300 Mg/m³
▸ Flue gas temperature: 131°C

exhaust gas mass flow at:
▸ Nominal power: 14.36 g/s
▸ Reduced power: 5.01 g/s
▸ Max. water temperature: 90°C
